SABdrain System Accessories
Drain Box
SABdrain DRAINBOX has been developed to be used in conjunction with the Sabdrain 704 cast iron grate range. by providing an inline pit along with the drainage system it has the advantages of increasing the head of water for outlet capacity while still providing aesthetics of linear design.
| Code | L | H | L1 | H1 | D1 | D2 | D3 | A | Kg |
|---|---|---|---|---|---|---|---|---|---|
| DRAINBX150 | 150 | 400 | 200 | 430 | 100 | 160 | 200 | 500 | 10.4 |
| DRAINBX200 | 200 | 400 | 250 | 430 | 100 | 160 | 200 | 500 | 12.5 |
End Caps
| Code | L | H | L1 | H1 |
|---|---|---|---|---|
| DREC10050 | 100 | 50 | 150 | 80 |
| DREC100100 | 100 | 50 | 150 | 130 |
| DREC150150 | 150 | 150 | 200 | 180 |
| DREC200150 | 200 | 150 | 250 | 180 |
| DREC200200 | 200 | 200 | 250 | 230 |
| DREC200300 | 200 | 300 | 250 | 330 |
| DREC300200 | 300 | 200 | 390 | 240 |
| DREC300300 | 300 | 300 | 390 | 330 |
| DREC508100 | 100 | 100 | 125 | 117 |
Install Clip
The Install-Clip is designed to support and clip two channels together. With a concept of one clip to fit all channels a fancy new design from Italy this clip can be flipped to meet the requirements and size from SAB500, SAB600, SAB700 & the SAB900 series.
| Code | Size |
|---|---|
| DRINSTALL | 100 - 150 - 200 - 300 |
